CEL Still on after replacing O2 sensor
#1
CEL Still on after replacing O2 sensor
Hi there,
I have 2002 Honda Accord SE 2.3L 2234CC L4 FI VIN: F23A4 - SOHC car.
The OBD Code reader shown the codes as P1166/P1167.
After inspecting at a famous service station, they identified that upstream O2 sensor need to be replaced. Based on internet search and mechanic suggestion, I purchased Denso Air Fuel Sensor Direct Fit (Part No. 234-9014) and installed it as per the instructions.
I was thinking that after 4-5 restarts or by erasing the code using OBD scanner will turn off the Check Engine Light, but that did not happen.
I drove the vehicle around 10 miles but I did not see the light going off!
I have to go for a State Inspection before the end of this month. I would appreciate, if anyone can help me fixing this problem.
Regards
Jay
I have 2002 Honda Accord SE 2.3L 2234CC L4 FI VIN: F23A4 - SOHC car.
The OBD Code reader shown the codes as P1166/P1167.
After inspecting at a famous service station, they identified that upstream O2 sensor need to be replaced. Based on internet search and mechanic suggestion, I purchased Denso Air Fuel Sensor Direct Fit (Part No. 234-9014) and installed it as per the instructions.
I was thinking that after 4-5 restarts or by erasing the code using OBD scanner will turn off the Check Engine Light, but that did not happen.
I drove the vehicle around 10 miles but I did not see the light going off!
I have to go for a State Inspection before the end of this month. I would appreciate, if anyone can help me fixing this problem.
Regards
Jay
#3
Those codes suggest an electrical problem w/ heater circuit on AF sensor. Since new AF sensor did not fix the problem, the fault must lie w/ fuse, wiring, or connector.
Did you check that same codes have reappeared? It's possible something else has failed.
good luck
Did you check that same codes have reappeared? It's possible something else has failed.
good luck
#4
I dont think there is any fault with fuse, wiring, or connector as it the AF sensor I replaced it an brand new OE (Denso AF Sensor, Part No. 234-9014). If I am overseeing something could you help me exactly what I need to check on my car?
When I checked with OBD2 scanner, I could see the same codes(P1166/P1167) reappearing. Will be there any separate devices which would erase the codes after this new AF sensor replacement?
When I checked with OBD2 scanner, I could see the same codes(P1166/P1167) reappearing. Will be there any separate devices which would erase the codes after this new AF sensor replacement?
#5
Did you have the OBDII code cleared AFTER you changed the sensor? If you didn't, you must have it done or else the CEL will stay ON until you have had a bunch of start/stop cycles. I don't remember the exact number but it's more than 3 or 4.
#7
Already tried but nouse :(
After installing the new AF Sensor, I tried clearing the codes with OBDII scanner but it appeared on restart! I did plenty of restarts, removed the battery conn... still the CEL appears!
#8
Rapid recurrence of the code means you likely have open/short in the circuit somewhere other than the new AF sensor and attached wiring.
It very well could be a faulty circuit in the ECU.
Inspect the engine harness side connector for the AF sensor and local wiring for damage.
If all looks OK, disconnect the connector at the AF sensor and check voltage at the heater leads (need wiring diagram to know which wires). One wire should have power (12v) when keyswitch is on and other wire should be 0V and grounded by ECU to enable. If ground from ECU is not available, suggest removing connector w/ ground wire at the ECU and checking continuity of this wire to the released sensor connector. Easiest way is to short one end of the wire to frame ground and check that ground is available at the other end. If not, there's a wiring/connector fault somewhere. If wire checks good, the ECU is likely the problem.
Check for used ECU's at ebay and car-part.com.
good luck
It very well could be a faulty circuit in the ECU.
Inspect the engine harness side connector for the AF sensor and local wiring for damage.
If all looks OK, disconnect the connector at the AF sensor and check voltage at the heater leads (need wiring diagram to know which wires). One wire should have power (12v) when keyswitch is on and other wire should be 0V and grounded by ECU to enable. If ground from ECU is not available, suggest removing connector w/ ground wire at the ECU and checking continuity of this wire to the released sensor connector. Easiest way is to short one end of the wire to frame ground and check that ground is available at the other end. If not, there's a wiring/connector fault somewhere. If wire checks good, the ECU is likely the problem.
Check for used ECU's at ebay and car-part.com.
good luck
#9
If you have a volt meter, you should check for voltage on the electrical connector going to the O2 sensor.
Use a metal bolt as your ground. Two of the pins should have voltage. I can't remember if they get 12V or 5V.
There are some resistance tests you can try as well to see if the wiring is damaged. Do you have a shop manual for your car?
Use a metal bolt as your ground. Two of the pins should have voltage. I can't remember if they get 12V or 5V.
There are some resistance tests you can try as well to see if the wiring is damaged. Do you have a shop manual for your car?
