Default I need some direction

I have decided to swap my f22 out the 94 and put in a h22 the only thing is i wanna switch it to a 5spd what needs to be done I am starting to pull the engine today I want to do it all myself the Haynes manual sucks it telling me take everything off the engine

  #2
Old 10-19-2009, 08:43 PM
WheelBrokerAng's Avatar
Administrator
Join Date: Aug 2004
Location: Canton/Massillon, Ohio 44646
Posts: 30,431
Talking Hi Member

I would run out to my car and get to AutoZone and go to the book shelf and buy this book that I keep telling everyone about in here.

Red Cover says...HONDA ENGINE SWAPS...BOOK # z93

WheelBrokerAng

Attached Thumbnails I need some direction-100_0991.jpg   I need some direction-100_0990.jpg
  #3
Old 10-20-2009, 04:56 AM
Junior Member
Thread Starter
Join Date: Oct 2009
Location: Florida
Posts: 61
Default Thanks

Thanks I will definitely go and pick that up thanks.

  #4
Old 10-20-2009, 06:34 AM
live2rice's Avatar
Super Moderator
Join Date: Oct 2006
Location: Alaska
Posts: 8,715
Default

1. 5 speed transmission (F22, F23, H22, H23)
2. 5 speed starter (90-02 Accord 92-02 prelude)
3. 5 speed shifter assembly w/ shifter cables (90-97 Accord, 92-96 Prelude)
4. 5 speed drivers side axle (your year accord, but from 5-spd version)
5. 5 speed intermediate shaft (your year accord, but from 5-spd version)
6. 5 speed clutch pedal assembly (90-97 Accord, 92-96 Prelude)
7. 5 speed brake pedal arm (90-93 Accord, 94-97 Accord)
8. Clutch master cylinder w/ reservoir and lines (90-97 Accord 92-96 Prelude)
9. Clutch line from Clutch master cylinder to clutch dampener (90-97 Accord 92-96 Prelude)
10. Clutch dampener assembly (90-97 Accord 92-96 Prelude)
11. Clutch line from Clutch dampener to 5 speed tranny (90-97 Accord 92-96 Prelude)
12. Clutch line from 5 speed tranny to slave cylinder (90-97 Accord 92-96 Prelude)
13. Slave cylinder (90-97 Accord 92-96 Prelude)
14. Clutch (90-02 Accord 92-01 Prelude)
15. Flywheel (90-02 Accord 92-01 Prelude)
16. 5 speed mount (Your year, 5-spd version)
17. 5 speed mount bracket (go to Honda - tell them to look for the bracket that is welded on the car - part is S.O.P and costs 15-25.00) (see notes)
18. MIG WELDER (see notes)
19. BOLTS: 8 Flywheel Bolts, 6 Pressure Plate Bolts, 3 Intermediate Shaft Bolts, 1 Long Tranny Bolt
